Maven Built
Maven RS.6 - 1-10x28 FFP Scope
Maven RS.6 - 1-10x28 FFP Scope
Couldn't load pickup availability
-
While most LVPOs available today start at 0-1x magnification and max out around 6-8x, we've bridged the gap between short-range and mid-range optics. Our design offers one of the best LVPOs on the market, excelling at 1x while also delivering exceptional performance and precision for mid-range applications.
The RS.6 features a versatile FFP reticle and a broad magnification range, paired with a premium optical system that enables quick target acquisition at close range while also allowing for accurate shots at distances of 300-500 yards - a capability uncommon in other LVPOs. Housed in a 34mm tube and compact 10.6-inch frame, the RS.6 is perfectly suited for your favorite hunting rifle or AR.
We’re excited to introduce a first-of-its-kind, tool-free locking elevation turret featuring a zero stop and a second rotation indicator, allowing for quick and easy reference of dialed elevation. With its tactile and straightforward design, adjusting the elevation is intuitive and fast. The push/pull locking mechanism ensures foolproof turret lock and re-zeroing, giving you an added layer of confidence in every shot.
Equipped with our award-winning RS Series glass, this distinctive scope delivers an exceptionally clear, bright, and high-contrast image with outstanding color fidelity. The viewing experience is further enhanced by a 5-level reticle illumination in both green and red. Choose between MOA (MOA3-LPI) and MIL (CFR2-LPI) reticle options, each surrounded by an illuminated quick acquisition ring for close-range shots and our popular holdovers for precision at longer distances.
Whether mounted on your AR or hunting rifle, the RS.6 will elevate your shooting performance and enhance your experience across a wide range of scenarios.
Includes neoprene cover.
Riflescope Comparison Chart (PDF)
Riflescope Manual (PDF)
Ballistics Calculator -
HIGHLIGHTS
-Premium Model
-Size: 10.6 in.
-Weight: 23.7 oz.
-First Focal Plane
-0.25 MOA/click or 0.1 MIL/click
-2 Reticle Options: MOA3-LPI and CFR2-LPI
-Multi-Stage Illuminated Reticle
-Mechanical Zero Stop
-34mm Tube
-Extra-Low Dispersion ED Glass
-Exceptionally Clear, Bright, High Contrast Image
-Excellent Color Fidelity
-Waterproof and Fog Proof
-Lifetime Warranty
-Direct to Consumer / No Retail Markup - RS.6 MOA RS.6 MIL Focal plane First Magnification range 1x - 10x Obj. lens diameter 28mm Tube diameter 34mm / 1.34in Objective outer diameter 34mm Eyepiece outer diameter 46mm Overall length 270mm / 10.6in Weight (without battery) 23.7oz / 570g Internal adjustment range (MOA/MIL) Travel Elevation 100 MOA 29 MIL Travel Windage 100 MOA 29 MIL Click value 0.250 MOA 0.1 MIL Adjustment per turret revolution 25 MOA 10 MIL Parallax adjustment 100y (fixed) Exit pupil diameter @1x: 8.1mm @10x: 2.8mm Eye relief @1x: 83-99mm @10x: 85-92mm Field of view @ 100y @1x: 116.6ft @10x: 11.7ft Front/Rear mounting length F: 64mm R: 56mm Effective objective lens diameter @1x: 8.1mm @10x: 28.0mm Field of view @1x: 22° @10x: 2.23° Field of view, apparent @1x: 22° @10x: 22° Diopter correction (dpt) +/-2 Light transmission 89.16% Twilight factor @1x: 5.3 @10x: 16.7 Functional temperature -4°~158°F Submersion tightness / waterproof rating 3m depth Gas purged Nitrogen Reticle construction Etched Glass Reticle options MOA-3 CFR-2 Illuminated reticle Y/N Yes Green/Red Origin Made in Japan
- Manual (PDF) Comparison Chart (PDF)
